575 GM 540 V-8 1986-1992 - Serial 0A677429 Thru 0D763716 - Drive Shaft And Tailstock (Drive Line)
Section Drawing: (Hover or click to view larger)
Other Sub-Sections:
- Alternator (55 Amp) - Motorola #8MR2039K
- Alternator (Motorola 8EM2003KA)
- Audio Warning System
- Crankshaft, Pistons And Connecting Rods (460)
- Cylinder Block And Camshaft
- Cylinder Head And Rocker Cover
- Distributor And Ignition Components
- Drive Shaft And Tailstock (Drive Line)
- Exhaust Manifold
- Flywheel Housing
- Fuel Pump, Carburetor And Linkage
- Intake Manifold And Front Cover
- Miscellaneous Parts-Accessories
- Mount Plates (Single, Side By Side Engines)
- Mount Plates (Staggered Engines)
- Oil Cooler (Transmission)
- Oil Cooler, Oil Filter And Adaptor
- Oil Pan And Oil Pump
- Power Steering Components (M0031-022)
- Power Steering Components (M0036-022)
- Reservoir Bottle
- Sea Water Pump Assembly
- Starter And Alternator
- Starter Motor
- Thermostat Housing And Water Hoses
- Transmission (Drive Line)
- Transmission (Plug-In)
- Wiring Harness, Electrical And Ignition
| Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
| 1 | 45-86978A3 | DRIVE SHAFT ASSEMBLY (37") | 1 | 45-86978A1 | |||||
| 1 | 45-53967A1 | DRIVE SHAFT ASSEMBLY (43") | 1 | This Part is No Longer Available | |||||
| 2 | 61218 | FLANGE, DRIVE SHAFT | 1 | ||||||
| 3 | 61221T | CROSS AND BEARING | 2 | 61221 | |||||
| 4 | 22-74036 | GREASE FITTING | 2 | ||||||
| 5 | 96276T4 | YOKE ASSEMBLY | 1 | 96276A2 | |||||
| 6 | 61218 | FLANGE, YOKE | 1 | ||||||
| 7 | 10-68743 | SCREW | 4 | This Part is No Longer Available | |||||
| 8 | 13-47659 | LOCKWASHER | 4 | ||||||
| 9 | 11-34933 | 676-9-72004 | NUT | 4 | |||||
| 10 | 52505A1 | DRIVE SHAFT EXTENSION | 1 | This Part is No Longer Available | |||||
| 11 | 19-47463 | PLUG | 1 | ||||||
| 12 | 23-47471T | BEARING | 1 | 23-47471 | |||||
| 13 | 10-60106 | SCREW | 4 | This Part is No Longer Available | |||||
| 14 | 12-45176 | WASHER | 4 | ||||||
| 15 | 55434A2 | DRIVE SHAFT EXTENSION HOUSING | 1 | This Part is No Longer Available | |||||
| 16 | 26-52499 | OIL SEAL | 1 | ||||||
| 17 | 22-36382 | 700-21887 | PIPE PLUG (1/4") | 1 | |||||
| 18 | 22-328022 | PIPE PLUG (1/8") | 1 | 22-32802 | |||||
| 19 | 22-47902 | FITTING | 1 | ||||||
| 20 | 15-49264A1 | SHIM SET | 1 | This Part is No Longer Available | |||||
| 21 | 30-47470 | BALL BEARING | 1 | ||||||
| 22 | 53-52502 | SNAP RING | 1 | ||||||
| 23 | 27-52501 | GASKET, BEARING SUPPORT HOUSING | 1 | ||||||
| 24 | 52506A1 | BEARING SUPPORT HOUSING | 1 | This Part is No Longer Available | |||||
| 25 | 31-47468T | NEEDLE BEARING | 1 | 31-47468 | This Part is No Longer Available | ||||
| 26 | 26-47465 | OIL SEAL | 1 | ||||||
| 27 | 53-52507 | RING, SUPPORT | 1 | This Part is No Longer Available | |||||
| 28 | 53-52503 | SNAP RING | 1 | This Part is No Longer Available | |||||
| 29 | 24-47755 | SPRING | 1 | ||||||
| 30 | 10-32695 | SCREW | 4 | ||||||
| 30 | 10-56393 | SCREW | 2 | ||||||
| 30 | 10-32515 | SCREW | 2 | ||||||
| 31 | 12-22248 | WASHER | 8 | ||||||
| 32 | 11-35053 | NUT | 8 |
