496 Mag Base Model - Serial 0W310000 Thru 0W649999 - Gasket Set Components (27-889924A02), Overhaul

Section Drawing: (Hover or click to view larger)

Untitled Document
Ref. OEM Part # Hardin # Mallory # GLM # Other # Description Num Req. Superceded From Special Notes
- 27-889924A02



GASKET SET, Overhaul 1
- 25-32509



O-RING, (.489 x .070) 4

- 26-42077



SEAL 3
- 27-46820
676-9-61400 700-33760
GASKET, Exhaust Manifold to Cylinder Head 2

- 27-49955
676-9-60104 700-30370
GASKET, Drain 2
- 25-8071341



SEAL 1
- 26-861947



SEAL 1
- 26-862957



SEAL, Oil Filter Adaptor 1
- 27-863112



GASKET, Idle Air Valve 1
- 27-863215



GASKET 2
- 27-863285



GASKET, Air Valve 1
- 26-865066



SEAL, Heat Exchanger to Crossover 2
- 27-879150064



GASKET 1
- 27-881603001



GASKET, Circulating Pump 2
- 27-881604



GASKET, Front Cover 1
- 26-881608001



SEAL, Rear Crankshaft 1
- 26-881613001



SEAL, Front Crankshaft 1
- 27-881612



GASKET, Oil Pan 1
- 27-881620001



GASKET, Cylinder Head to Crossover 2
- 27-881622



GASKET, Cylinder Head Cover 2
- 26-881637T



SEAL, Valve Stem Oil 16
- 27-895235



GASKET SET, Intake Manifold and Valley 1
- 27-881631



GASKET, Cylinder Head 1
