250 VERADO 4-STROKE 6 CYL - Serial 0P464488 Thru 0P520552 - Tools
Section Drawing: (Hover or click to view larger)
Other Sub-Sections:
- Adaptor Plate Hose Routings
- Adaptor Plate-Lower
- Alternator/Belt Tensioner Mounting
- Charge Cooler/Intake Manifold
- Charge Cooler/Intake Manifold Hose Routings
- Cowl Latching
- Crankshaft, Pistons and Connecting Rods
- Cylinder Block
- Cylinder Head and Camshaft
- Driveshaft Housing
- Electrical Box Components
- Fuel Supply Module
- Gear Housing(Driveshaft)(Standard/Counter Rotation)
- Gear Housing, Propeller Shaft - Counter Rotation
- Gear Housing, Propeller Shaft - Standard Rotation
- Induction Components
- Mercathode Kit
- Mount Cradle
- Oil Pump/Adaptor Plate-Upper
- Port Cylinder Block Components
- Power Trim Components
- Power Trim/Steering Cylinder
- Powerhead Gasket Set Components
- Rear Cowl
- Starboard Cylinder Block/Oil Cooler
- Starter Motor/Electrical Cable Bracket Mounting
- SuperCharger
- Tools
- Top Cowl
- Upper Shift Components
| Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
| - | 91-889277Q03 | TOOL, Wrench (75 mm x 30) Flute | 1 | 895277001 | |||||
| - | 91-809905001 | WRENCH, Torque Adaptor | 1 | ||||||
| - | 91-822778004 | TOOL, Adaptor Fitting-Power Trim | 1 | ||||||
| - | 91-895343T02 | TOOL, Flywheel Puller | 1 | ||||||
| - | 10-895346 | BOLT | 1 | ||||||
| - | 91-896504A01 | TOOL ASSEMBLY, OB Lifting Mech | 1 | ||||||
| - | 889675A01 | TOOL, Shunt 14-Pin | 1 | ||||||
| - | 91-804998T | DRAIN/FILL TOOL, Gearlube | 1 | ||||||
| - | 91-896661 | TOOL, Fuel Filter | 1 | ||||||
| - | 889283A01 | TOOL KIT, Fuel Priming | 1 |
