Rotary Steering Systems & Replacement Cables:

WARNING:  Although Teleflex designs cable systems that meet or exceed all existing industry standards and certifications, it should be noted that some high performance boats equipped with high performance accessories, such as motor jack plates and high performance propellers, can generate steering loads far in excess of 300 lbs. at the tiller end. It is mandatory that boats equipped with high performance equipment or accessories be water tested to insure that steering loads are within safe operating limits.

Click on the part number to check pricing or place an order.

Teleflex SS137 Rotary Steering System

The ultimate packaged rotary steering system.

At last, a superior, complete, all in one, steering system in a box!  Complete steering systems include cable, helm, a 90º bezel and instructions.  Optional 20º bezel or tilt-helm are available.

  • New standard in cable design—smoother, easier action with less loss of motion than ever before.

  • An extremely affordable, complete rotary steering system kit that saves you time and money!
  • Quick and easy installation instructions included in every kit.
  • Extreme durability die casting and 1 piece steel shaft with precision drive gear.
  • Close tolerance core reduces liner contact for effortless movement.
  • 3 turning revolutions from lock to lock.

Application Guide

  • Generally, the SS137system can be used on boats up to 35' in length.
  • 300 lb. maximum working load at the tiller arm.
  • The SS137 steering system should NOT be used on boats equipped with engines that exceed the maximum horsepower rating of the boat.
Part No. Description
620-3080* SS137 Rotary Steering System
Available in lengths from 5' to 30' in 1' incremental lengths.
SS137 Replacement Rotary Steering Cables

  • Superior replacement steering cable for Morse® Command 250, 290, Teleflex® Big T™, non-feedback and snap-in-helms.

  • Setting the standard in cable design: Smoother, easier action with less loss of motion than ever before

All SS137 replacement rotary steering cables are available in lengths from 5' to 30' in 1' incremental lengths.

Part No. Description
620-4620* SS137 Rotary replacement cable only
